Hitec HS-85BB Premium Micro Servo

Original price $23.99 - Original price $23.99
Original price
$23.99
$23.99 - $23.99
Current price $23.99
Availability:
in stock, ready to be shipped

The HS-85BB features a high power motor for greater speed and torque. The HS-85BB is the choice of modelers looking for a high performance servo without breaking the bank. The ball bearing supported output shaft and sturdy gear trains are preferred for smaller glow and electric airplanes, heli’s and sail planes.

Features

  • High Torque and Precision Centering
  • Strong Resin Gear Train
  • Ball Bearing-Supported Output Shaft
  • Perfect for Applications where a Standard Servo is too Heavy or Large but Standard Torque is Required

Accessories

  • Nylon Gear Set
  • Plastic Case Set
  • Applicable Horns

HS-85BB Servo Specifications

Performance Specifications
Operating Voltage Range (Volts DC) 4.8V ~ 6.0V
Speed (Second @ 60°) 0.16 ~ 0.14
Maximum Torque Range oz. / in. 42 ~ 49
Maximum Torque Range kg. / cm. 3.0 ~ 3.5
Current Draw at Idle 8 mA
No Load Operating Current Draw 280 mA
Stall Current Draw 1,200 mA
Dead Band Width 8 µs
Physical Specifications
Dimensions (Inches) 1.14 x 0.51 x 1.18
Dimensions (Metric) 29.0 x 13.0 x 30.0
Weight (Ounces) 0.67
Weight (Gram) 19.2
Circuit Type HT7003 Analog SMT
Motor Type 3 Pole Metal Brush Ferrite
Gear Material Nylon
Bearing Type Top Ball Bearing
Output Shaft (type / Ømm) Standard 24
Case Material Plastic
Dust / Water Resistance N / A
Connector Gauge (AWG) / Strand Count 28 / 20
Radio Control Applications
Parkflyer N / A
Sport Plane >40%
Sailplane N / A
3D Performance N / A
Scale >40%
Electric Helicopter N / A
Gas Helicopter N / A
On Road 1/4th & 1/5th
Monster Truck 1/4th & 1/5th
Buggies 1/4th & 1/5th
Truggies 1/4th & 1/5th
Short Course / Truck 1/4th & 1/5th
Crawlers N / A
Sail Boat N / A
Power Boat N / A
