JZ T40 Spotlight for DJI Matrice 4D/4TD Series Drones
This Item Ships FREE
Description
JZ T40 40W LED Spotlight for DJI Matrice 4T / 4E / 4D / 4TD
The JZ T40 40W LED Spotlight is a powerful, lightweight aerial lighting solution designed for the DJI Matrice 4T, Matrice 4E, Matrice 4D, and Matrice 4TD enterprise drones. Featuring a high-output 40W LED spotlight, brushless self-stabilizing gimbal, multi-color warning lights, and camera-linked lighting control, the JZ T40 delivers exceptional versatility for law enforcement, search and rescue, emergency response, security, and professional nighttime drone operations.
Weighing just 95.6 grams, the JZ T40 combines a compact, integrated design with impressive lighting performance. Its 14° concentrated beam provides focused illumination at distances of up to 150 meters (492 feet), delivering 30 lux at 50 meters and approximately 3 lux at 150 meters.
The integrated brushless self-stabilizing gimbal provides precise tilt adjustment from -90° to +35° and supports camera gimbal linkage, allowing the spotlight to follow the drone's camera direction for consistent illumination. Six integrated RGB LEDs provide multiple warning light colors, while adjustable brightness and high-intensity flashing modes offer additional flexibility for demanding aerial operations.
With an IP54 protection rating and an operating temperature range of -20°C to +50°C, the JZ T40 is engineered for reliable performance in challenging environments.
The JZ T40 is also available in a T40P version featuring an integrated visible laser sight for precise visual indication.
Key Features
- Powerful 40W LED Spotlight: Delivers high-intensity illumination for nighttime aerial operations, search missions, and inspections.
- 150-Meter Lighting Range: Provides focused illumination at distances of up to 150 meters (492 feet).
- 14° Concentrated Beam: Optimized lighting design delivers high central illuminance with effective coverage of distant areas.
- Brushless Self-Stabilizing Gimbal: Integrated brushless gimbal maintains stable lighting and supports precise directional control.
- Extended -90° to +35° Tilt Range: Allows operators to illuminate areas directly below the drone or adjust the spotlight upward as needed.
- Camera-Linked Gimbal Control: Supports synchronization between the spotlight gimbal and drone camera for consistent lighting alignment.
- Six Integrated RGB LEDs: Provides multiple colored lighting and warning modes for versatile aerial applications.
- Five Warning Light Colors: Supports red, green, blue, yellow, and white lighting with convenient real-time switching.
- Adjustable Brightness: Easily adjust light intensity to accommodate different operational requirements.
- High-Intensity Flashing Modes: Supports strong light flashing and multi-color warning functions for visual signaling.
- Lightweight 95.6g Design: Compact construction minimizes additional payload weight while maintaining powerful lighting performance.
- IP54 Weather Resistance: Designed to resist dust ingress and water splashes during outdoor operations.
- Wide Operating Temperature Range: Supports operation in temperatures ranging from -20°C to +50°C.
- DJI Matrice 4 Series Compatibility: Compatible with the DJI Matrice 4T, 4E, 4D, and 4TD, with an included mounting bracket for Matrice 4T/4E aircraft.
Advanced Lighting and Gimbal Functions
High-Output LED Illumination
The JZ T40 features a powerful 40W LED spotlight with a concentrated 14° beam angle, providing targeted illumination for nighttime missions. The spotlight delivers approximately 30 lux at 50 meters, 7 lux at 100 meters, and 3 lux at 150 meters.
This focused lighting design allows operators to illuminate structures, terrain, vehicles, and other areas of interest from a distance while maintaining useful light intensity.
Brushless Self-Stabilizing Gimbal
Unlike fixed-mounted spotlights, the JZ T40 incorporates a brushless self-stabilizing gimbal capable of tilting from -90° to +35°. This extended adjustment range provides greater flexibility when illuminating objects at different elevations or angles.
The spotlight also supports camera gimbal linkage, allowing the lighting direction to follow the drone's camera for more efficient nighttime observation and inspection.
Multi-Color RGB Warning Lights
Six integrated RGB LEDs support five selectable lighting colors: red, green, blue, yellow, and white. Operators can switch between colors in real time to accommodate different mission requirements.
The multi-color warning function offers additional versatility for public safety operations, emergency response, scene identification, and visual signaling.
Adjustable Brightness and Flashing Modes
The JZ T40 supports adjustable brightness, high-intensity flashing, and multi-color warning modes. These functions allow operators to customize the spotlight's output for illumination, signaling, or attention-getting applications.
Optional Visible Laser Sight – T40(P) Version
The JZ T40(P) incorporates a built-in visible laser sight for precise visual indication and targeting of areas of interest. The laser allows operators to identify specific locations or objects within the spotlight's illuminated area.
The standard JZ T40 does not include the visible laser sight. Select the T40(P) version if laser indication functionality is required.
Ideal Applications
The JZ T40 LED Spotlight is designed for professional drone operators requiring reliable aerial illumination and versatile warning light capabilities.
- Law Enforcement: Nighttime searches, aerial observation, scene illumination, and public safety operations.
- Search and Rescue: Illuminate search areas, identify points of interest, and support ground teams during nighttime rescue missions.
- Fire and Emergency Response: Provide aerial illumination during incident assessments, emergency response, and disaster recovery operations.
- Security and Surveillance: Illuminate facilities, properties, and remote areas during nighttime monitoring and patrols.
- Industrial Inspections: Enhance visibility when inspecting infrastructure, rooftops, utility installations, and structures in low-light environments.
- Public Safety and Signaling: Utilize adjustable flashing modes and multi-color warning lights for visual signaling and identification.
Lighting Performance
The JZ T40's concentrated 14° beam provides effective illumination across a range of operational distances.
| Distance | Coverage Area | Illuminance |
|---|---|---|
| 50 meters (164 ft) | 113 m² | 30 lux |
| 100 meters (328 ft) | 471 m² | 7 lux |
| 150 meters (492 ft) | 1,063 m² | 3 lux |
Technical Specifications
| Specification | Details |
|---|---|
| Model | JZ T40 / T40P |
| Product Type | LED Spotlight with RGB Warning Lights |
| Lighting Power | 40W |
| Weight | 95.6g |
| Dimensions | 146 × 72 × 30mm |
| Beam Angle | 14° |
| Maximum Lighting Range | 150m (492 ft) |
| Illuminance at 50m | 30 lux |
| Illuminance at 100m | 7 lux |
| Illuminance at 150m | 3 lux |
| RGB LEDs | 6 Integrated LEDs |
| Warning Light Colors | Red, Green, Blue, Yellow, White |
| Brightness Adjustment | Supported |
| Flashing Modes | Supported |
| Gimbal Type | Brushless Self-Stabilizing Gimbal |
| Gimbal Tilt Range | -90° to +35° |
| Camera Gimbal Linkage | Supported |
| Visible Laser Sight | T40P Version Only |
| Protection Rating | IP54 |
| Operating Temperature | -20°C to +50°C |
| Storage Temperature | -20°C to +60°C |
| Compatible Drones | DJI Matrice 4T / 4E / 4D / 4TD |
Compatibility Information
Compatible Drones:
- DJI Matrice 4T
- DJI Matrice 4E
- DJI Matrice 4D
- DJI Matrice 4TD
The JZ T40 is designed for compatibility across the DJI Matrice 4 enterprise drone lineup.
DJI Matrice 4T / 4E: Requires the included mounting bracket for installation.
DJI Matrice 4D / 4TD: Compatible with the Matrice 4D and 4TD series, providing a lighting solution for these aircraft.
Model Selection:
- JZ T40: 40W LED Spotlight with RGB Warning Lights
- JZ T40P: 40W LED Spotlight with RGB Warning Lights and Built-In Visible Laser Sight
Drone not included.
Upgrade Your DJI Matrice 4 Series Drone with Professional Aerial Lighting
Equip your DJI Matrice 4T, 4E, 4D, or 4TD with the JZ T40 40W LED Spotlight for powerful nighttime illumination, stabilized directional lighting, and versatile multi-color warning functions.
With its lightweight construction, 150-meter lighting range, brushless self-stabilizing gimbal, and IP54 weather resistance, the JZ T40 is an excellent lighting solution for demanding public safety, emergency response, industrial inspection, and enterprise drone operations.
For operators requiring additional precision, the JZ T40(P) version adds an integrated visible laser sight, providing enhanced visual indication capabilities.
Specifications
In The Box
JZ T40 40W LED Spotlight for DJI Matrice 4T / 4E / 4D / 4TD
The JZ T40 40W LED Spotlight is a powerful, lightweight aerial lighting solution designed for the DJI Matrice 4T, Matrice 4E, Matrice 4D, and Matrice 4TD enterprise drones. Featuring a high-output 40W LED spotlight, brushless self-stabilizing gimbal, multi-color warning lights, and camera-linked lighting control, the JZ T40 delivers exceptional versatility for law enforcement, search and rescue, emergency response, security, and professional nighttime drone operations.
Weighing just 95.6 grams, the JZ T40 combines a compact, integrated design with impressive lighting performance. Its 14° concentrated beam provides focused illumination at distances of up to 150 meters (492 feet), delivering 30 lux at 50 meters and approximately 3 lux at 150 meters.
The integrated brushless self-stabilizing gimbal provides precise tilt adjustment from -90° to +35° and supports camera gimbal linkage, allowing the spotlight to follow the drone's camera direction for consistent illumination. Six integrated RGB LEDs provide multiple warning light colors, while adjustable brightness and high-intensity flashing modes offer additional flexibility for demanding aerial operations.
With an IP54 protection rating and an operating temperature range of -20°C to +50°C, the JZ T40 is engineered for reliable performance in challenging environments.
The JZ T40 is also available in a T40P version featuring an integrated visible laser sight for precise visual indication.
Key Features
- Powerful 40W LED Spotlight: Delivers high-intensity illumination for nighttime aerial operations, search missions, and inspections.
- 150-Meter Lighting Range: Provides focused illumination at distances of up to 150 meters (492 feet).
- 14° Concentrated Beam: Optimized lighting design delivers high central illuminance with effective coverage of distant areas.
- Brushless Self-Stabilizing Gimbal: Integrated brushless gimbal maintains stable lighting and supports precise directional control.
- Extended -90° to +35° Tilt Range: Allows operators to illuminate areas directly below the drone or adjust the spotlight upward as needed.
- Camera-Linked Gimbal Control: Supports synchronization between the spotlight gimbal and drone camera for consistent lighting alignment.
- Six Integrated RGB LEDs: Provides multiple colored lighting and warning modes for versatile aerial applications.
- Five Warning Light Colors: Supports red, green, blue, yellow, and white lighting with convenient real-time switching.
- Adjustable Brightness: Easily adjust light intensity to accommodate different operational requirements.
- High-Intensity Flashing Modes: Supports strong light flashing and multi-color warning functions for visual signaling.
- Lightweight 95.6g Design: Compact construction minimizes additional payload weight while maintaining powerful lighting performance.
- IP54 Weather Resistance: Designed to resist dust ingress and water splashes during outdoor operations.
- Wide Operating Temperature Range: Supports operation in temperatures ranging from -20°C to +50°C.
- DJI Matrice 4 Series Compatibility: Compatible with the DJI Matrice 4T, 4E, 4D, and 4TD, with an included mounting bracket for Matrice 4T/4E aircraft.
Advanced Lighting and Gimbal Functions
High-Output LED Illumination
The JZ T40 features a powerful 40W LED spotlight with a concentrated 14° beam angle, providing targeted illumination for nighttime missions. The spotlight delivers approximately 30 lux at 50 meters, 7 lux at 100 meters, and 3 lux at 150 meters.
This focused lighting design allows operators to illuminate structures, terrain, vehicles, and other areas of interest from a distance while maintaining useful light intensity.
Brushless Self-Stabilizing Gimbal
Unlike fixed-mounted spotlights, the JZ T40 incorporates a brushless self-stabilizing gimbal capable of tilting from -90° to +35°. This extended adjustment range provides greater flexibility when illuminating objects at different elevations or angles.
The spotlight also supports camera gimbal linkage, allowing the lighting direction to follow the drone's camera for more efficient nighttime observation and inspection.
Multi-Color RGB Warning Lights
Six integrated RGB LEDs support five selectable lighting colors: red, green, blue, yellow, and white. Operators can switch between colors in real time to accommodate different mission requirements.
The multi-color warning function offers additional versatility for public safety operations, emergency response, scene identification, and visual signaling.
Adjustable Brightness and Flashing Modes
The JZ T40 supports adjustable brightness, high-intensity flashing, and multi-color warning modes. These functions allow operators to customize the spotlight's output for illumination, signaling, or attention-getting applications.
Optional Visible Laser Sight – T40(P) Version
The JZ T40(P) incorporates a built-in visible laser sight for precise visual indication and targeting of areas of interest. The laser allows operators to identify specific locations or objects within the spotlight's illuminated area.
The standard JZ T40 does not include the visible laser sight. Select the T40(P) version if laser indication functionality is required.
Ideal Applications
The JZ T40 LED Spotlight is designed for professional drone operators requiring reliable aerial illumination and versatile warning light capabilities.
- Law Enforcement: Nighttime searches, aerial observation, scene illumination, and public safety operations.
- Search and Rescue: Illuminate search areas, identify points of interest, and support ground teams during nighttime rescue missions.
- Fire and Emergency Response: Provide aerial illumination during incident assessments, emergency response, and disaster recovery operations.
- Security and Surveillance: Illuminate facilities, properties, and remote areas during nighttime monitoring and patrols.
- Industrial Inspections: Enhance visibility when inspecting infrastructure, rooftops, utility installations, and structures in low-light environments.
- Public Safety and Signaling: Utilize adjustable flashing modes and multi-color warning lights for visual signaling and identification.
Lighting Performance
The JZ T40's concentrated 14° beam provides effective illumination across a range of operational distances.
| Distance | Coverage Area | Illuminance |
|---|---|---|
| 50 meters (164 ft) | 113 m² | 30 lux |
| 100 meters (328 ft) | 471 m² | 7 lux |
| 150 meters (492 ft) | 1,063 m² | 3 lux |
Technical Specifications
| Specification | Details |
|---|---|
| Model | JZ T40 / T40P |
| Product Type | LED Spotlight with RGB Warning Lights |
| Lighting Power | 40W |
| Weight | 95.6g |
| Dimensions | 146 × 72 × 30mm |
| Beam Angle | 14° |
| Maximum Lighting Range | 150m (492 ft) |
| Illuminance at 50m | 30 lux |
| Illuminance at 100m | 7 lux |
| Illuminance at 150m | 3 lux |
| RGB LEDs | 6 Integrated LEDs |
| Warning Light Colors | Red, Green, Blue, Yellow, White |
| Brightness Adjustment | Supported |
| Flashing Modes | Supported |
| Gimbal Type | Brushless Self-Stabilizing Gimbal |
| Gimbal Tilt Range | -90° to +35° |
| Camera Gimbal Linkage | Supported |
| Visible Laser Sight | T40P Version Only |
| Protection Rating | IP54 |
| Operating Temperature | -20°C to +50°C |
| Storage Temperature | -20°C to +60°C |
| Compatible Drones | DJI Matrice 4T / 4E / 4D / 4TD |
Compatibility Information
Compatible Drones:
- DJI Matrice 4T
- DJI Matrice 4E
- DJI Matrice 4D
- DJI Matrice 4TD
The JZ T40 is designed for compatibility across the DJI Matrice 4 enterprise drone lineup.
DJI Matrice 4T / 4E: Requires the included mounting bracket for installation.
DJI Matrice 4D / 4TD: Compatible with the Matrice 4D and 4TD series, providing a lighting solution for these aircraft.
Model Selection:
- JZ T40: 40W LED Spotlight with RGB Warning Lights
- JZ T40P: 40W LED Spotlight with RGB Warning Lights and Built-In Visible Laser Sight
Drone not included.
Upgrade Your DJI Matrice 4 Series Drone with Professional Aerial Lighting
Equip your DJI Matrice 4T, 4E, 4D, or 4TD with the JZ T40 40W LED Spotlight for powerful nighttime illumination, stabilized directional lighting, and versatile multi-color warning functions.
With its lightweight construction, 150-meter lighting range, brushless self-stabilizing gimbal, and IP54 weather resistance, the JZ T40 is an excellent lighting solution for demanding public safety, emergency response, industrial inspection, and enterprise drone operations.
For operators requiring additional precision, the JZ T40(P) version adds an integrated visible laser sight, providing enhanced visual indication capabilities.
