T-Motor / T-Hobby AM600 525kv Brushless Motor

T-Motor / T-Hobby AM600 525KV Brushless Motor for 60–64" 3D RC Airplanes

The T-Motor / T-Hobby AM600 525KV Brushless Motor is a powerful, lightweight motor designed for 60–64 inch 3D RC airplanes, freestyle aircraft, and high-performance aerobatic models. Built for pilots who demand fast throttle response, strong torque, and dependable power, the AM600 is an excellent choice for aggressive 3D flying, hovering, waterfalls, harriers, and precision aerobatics.

Optimized for 6S LiPo power, the AM600 525KV uses T-Hobby's large-diameter motor design to generate increased torque while improving airflow and cooling. Paired with the recommended T16x8 propeller, the AM600 is capable of producing up to approximately 8.3 kg (18.3 lb) of thrust, providing excellent vertical performance and recovery authority for 60–64" class 3D aircraft.

The AM600 also features T-Hobby's hollowed lightweight construction, reducing unnecessary motor weight while maintaining the strength required for demanding aerobatic flight. At approximately 360 grams including cables, it delivers an impressive power-to-weight ratio without adding excessive weight to the aircraft.

Key Features:

• 525KV high-torque brushless outrunner motor

• Designed for 60–64" 3D and aerobatic RC airplanes

• Ideal for approximately 3–4 kg aircraft

• Optimized for 6S LiPo batteries (22–25V)

• Produces up to approximately 8.3 kg / 18.3 lb of thrust

• Lightweight hollowed construction for improved strength-to-weight ratio

• Large-diameter design provides excellent torque and rapid throttle response

• Approximate motor weight: 360 g including cables

• Maximum rated power: 1700W for up to 180 seconds

• Peak current: 86A for up to 180 seconds

• Internal resistance: 12mΩ

• 24N20P motor configuration

• 8mm shaft diameter

• Recommended ESC: T-Hobby AM116A

• Recommended propeller: T16x8

Whether you're building a lightweight 60", 62", or 64" electric 3D airplane, the T-Hobby AM600 525KV motor provides the thrust, torque, and responsive power delivery needed for confident hovering, explosive vertical climbs, and demanding freestyle aerobatics. Its combination of low weight, strong 6S performance, and T-Motor build quality makes it an excellent power choice for serious 3D RC pilots.
